EPSILON™ Siren Series
Economical, Self-Contained
100 Watt Electronic Siren
EPSL1 - 100 watt siren amplifier with
Scan-Lock™ siren tones and
real time Diagnostix™, 12 VDC
The new Epsilon siren
is designed to meet SAE
Class A sound requirements
when used with most 100
watt siren speakers. Epsilon
features hands-free and
public address operation,
Scan-Lock™ multiple warning
tones and horn ring override
capability with real time
diagnostics.
Feaures:
Meets SAE Class A sound
requirements when used with
most 100 watt speakers.
California Title 13 ready.
Long lasting LED backlighting.
Real time diagnostics indicator.
When the indicator is
steady, the siren is operating
correctly. If it single flashes,
the speaker is short circuited;
and, if the indicator is off, the
speaker is under current.
Nine Scan-Lock™ siren tones
to choose from: tone off, wail,
yelp, air horn, Hi/Low, Piercer,
Y249, manual wail coast to
stop, and manual wail stop.
Hands-free operation from the
vehicle steering wheel.
Scan-Lock switch is located on
the rear for security of the unit
to ensure that all of the fleets'
sirens are set with the same
tones.
Installation package includes
all the necessary mounting
hardware and input pigtail
connector.
Front of unit provides a PA
volume control knob for the
noise-cancelling microphone,
On/Off switch, manual button
and 7-position rotary switch.
Rotary switch allows choice
of standby for use with the
manual button, manual tone
1 & 2. Hands-free position
allows horn ring operation of
the siren and tone 1, 2 and 3
positions. Each of these tone
positions has an override tone
when the manual button is
depressed.
Easy to install. Pre-wired
with quick disconnect plug
for easy service and prompt
replacement.
Twenty-four month warranty.
Dimensions: 2-1/4” (57mm) H
x 5-7/8” (149mm) W
x 5-3/4” (146mm)D.
Weight: 2 lbs. 11 oz.
Requires at least one 100 watt speaker. (not included, sold separately)
