Thin, low profile exterior light with black powder coated metal housing using TIR optical technology coupled with (6) high powered LEDs providing exceptional straight-on and off-angle performance.
Benefits:
Surface Mount, Flush Mount and Hood Mount allow mounting virtually anywhere on your vehicle
High powered, water resistant, compact LEDs with TIR Optic Technology provide exceptional straight on and off-angle performance.
Design Features:
TIR Optic LED Lightheads
(6) High Powered LEDs in Red, Blue, Amber, or White
Split Models available in R/B, R/W, B/W, B/A, A/W colors
13 User Selectable Flash Patterns including Steady Burn
Sychronous Capabilities with other MR6 Lights
Simultaneous or Alternating Flashing
Standard Options:
Available in Surface, Hood or Flush Mount (with grommet) Configurations
(2) screw mounting holes for surface and flush mount
Hood Mount can be mounted (3) different ways: (1) two fastener, clamping style (no holes need to be drilled); (2) through hole; and (3) double sided-tape.
Specifications:
Surface Mount Unit: 5.25” L x 0.77” D x 1.10” W(133.4 mm x 19.6 mm x 28 mm)
MR6 (Flush Mount) with Grommet (MR6FHKIT) size = 1.62” L x .67” D nbsp;x 5.77” W (17mm x 41.1mm x 146.5mm)
MR6 Hood Mount with Clamp Type Assembled size = 4.22” L x 1.80” D x 1.50” W(45.7mm x 38.1mm x 107.1mm)
MR6 Hood Mount Permanent Mount Type size = 4.22” L x 1.68” D x 1 .00”W(42.6mm x 25.4mm x 107.1mm)
12/24 Volt
Meets SAE J595, California Title 13 when properly configured
ECE 65 Specifications for International Requirements
5-Year Warranty on LEDs
